Abyzz A200 AU Water Pump 3m

$3,495.95

Out of stock

Description

Abyzz A200
MAX FLOW – 14,000 LPH | MAX HEAD – 9.5 METRES

These pumps only contain the highest quality parts to make an incredibly reliable, efficient controllable DC water pump. Featuring laser welded atitanium encased Neodymium rotor, powerful and programmable menu-controlled electronic driver, and a sinusoidal three-phase synchronous motor, the A200 is in a class of it’s own in terms of size and performance.

The motor operates at an efficiency factor of over 90% which, along with the fact that you can adjust the speed to meet your performance requirements, makes it an energy-saving solution to traditional power hungry higher voltage pumps. The menu controlled driver and motor run on an mere 12V and because of that it can be used in a myriad of applications.

The integrated flushing bearing provides optimum protection against calcification (Calcium Carbonate deposits – CaCO3). In conjunction with the silicon carbide bearings and special Tungsten carbide shaft, this feature provides for low-maintenance operations. The materials used to manufacture all of these components have been carefully selected so as to be harmoniously integrated into the overall design to look great, ensure a long operational lifetime, and meet the most demanding requirements and highest quality standards.

Applications

  • Freshwater and Saltwater Aquaria
  • Ponds
  • Creeks
  • Pools
  • Spas
  • Hydroculture
  • Aquaculture

Features:

·       16655 LPH BOOSTMODE® max flow rate

·       Internal or External application

·       Fully Controllable from 0-100% in 1% increments

·       MCFS® (Menu Controlled Flow Sequencer) for random, wave etc.

·       Comprehensive safety functions (e.g. dry run, temperature sensor, and overload protection)

·       Soft startup

·       Lockable cables and plug connections

·       Remarkably low-noise operation

·       Removable motor stand and rotatable volute

·       Available in 3meter & 10m Driver/Controller Connecting Cable

·       12 month Australian warranty* – Extended Warranty is available directly through Abyzz Germany**.



ABYZZ A200-3M DC PUMP SPECIFICATIONS

BOOSTMODE® max flow rate: 4,400 gph / 17,000 lph
Normal mode max flow rate: 3,750 gph / 14,000 lph
Max delivery height: 31 ft / 9.4 meters
Rated input: 4-200W
Input voltage: 110V~ @ 60Hz
Operating Voltage: 200V
Ambient temperature: 35.5°F – 104°F / +2°C – 40°C
Maximum operating pressure: 21.75 psi / 1,5 bar
Maximum immersion depth: 6.5 ft / 2 meters
Pump cable length: 9.75 ft/ 3m
Inlet/outlet connections: 2”/ 1.5” (50mm/40mm) suitable for PVC/AVB adhesive fittings

Whats Included

  • Abyzz A200 pump
  • 110V 60Hz driver
  • 5ft power cable
  • Driver/Controller connecting cable: 3M/9.75 ft or 10M/32.5 ft
  • Operating manual
